IVSS7008

IVSS7008-1I – Video Surveillance Server WizMind Intelligent AI NVR

SKU: IVSS7008-1I Categories: , , , Tags: , , , , ,

> Microcontrollore integrato nel settore
> Larghezza di banda in entrata massima di 400 Mbps
> Accesso video IP a 128 canali
> Protezione perimetrale fino a 16 canali
> Riconoscimento facciale fino a 6 canali per dispositivo
> Riconoscimento facciale fino a 20 canali tramite telecamera
> Metadati video fino a 4 canali
> Fino a 50 database di volti con 300.000 immagini di volti in totale
> Supporta RAID 0/1/5/6/10
> SAS3.0 per l’estensione dello spazio di archiviazione
> Uscita video 3HDMI / 2VGA

Specifiche tecniche IVSS7008-1I

Sistema

Main ProcessorIndustry embedded micro-controller
Operating SystemEmbedded Linux OS
Operation InterfaceWEB (PCAPP), local GUI
AI Applications
AI by CameraFace detection, face recognition, video metadata,

IVS (tripwire, intrusion, missing object, and more),

people counting, smoking detection, call detection

AI by DeviceFace detection, face recognition, video metadata,

IVS (tripwire, intrusion, missing object, and more), people counting, smoking detection, call detection

IVS

IVS Performance (AI by Device) (Channel Number)General model: 16-channel

Advanced model: 4-channel

IVS Performance (AI by Camera) (Channel Number)64-channel

Human Face Detection

Human Face PropertiesSupports 6 properties: Gender, age, glasses, expression, mouth mask, and beard.
Face Detection Performance (AI by Device) (1080P) (Channel Number)8-channel
Face Detection Performance (AI by camera) (Channel Number)20-channel

Human Face Recognition

Face Database Capacity50 face databases with 300,000 face pictures in total
Human Face Recognition Performance (AI by Device) (1080P)(Channel Number)8-channel with normal IP camera

20-channel with face detection IP camera (Totally 20 face pictures analyzed per second)

Human Face Recognition Performance (AI by camera) (Channel Number)20-channel

ANPR

Plate Database Capacity50 plate databases with 300,000 plate numbers in total
Supports allowlist and blocklist
Plate Detection Performance by ITC Camera (Channel Number)32-channel

Video Metadata

Human Body PropertiesGender, age, sleeves length, top color, bottom type, bottom color, bag, rain coat, umbrella, hat, hairstyle, direction, hold a baby, mouth mask
Vehicle PropertiesVehicle type, vehicle color, plate color, logo, calling, seatbelt, ornament, region
Non-motorized Vehicle PropertiesNon-motor Vehicle type, non-motor vehicle color, number of passengers, umbrella, rain coat,bag , sleeve length, top color, hat, hair style, mouth mask
Metadata Performance (AI by Device) (1080P) (Channel Number)4-channel
Metadata Performance (AI by camera) (Channel Number)32-channel

Parametri video

Remote Connection128-channel
Network BandwidthIncoming bandwidth: 400Mbps
recording bandwidth: 320Mbps
outgoing bandwidth: 96Mbps
Resolution16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/CIF/QCIF
Decoding Capability2-channel 16MP/5-channel 12MP (20fps)/6-channel 12MP (15fps)/5-channel 8MP (30fps)/10-channel 8MP (15fps)/6-channel 6MP(30fps)/8-channel 5MP(30fps)/9-channel 5MP (25fps)/10-channel 4MP (30fps)/15-channel 4MP (20fps)/16-channel 3MP (25fps)/10-channel 1080P (60fps)/20-channel 1080P (30fps)/30-channel 720P (30fps)
Video Output2-channel VGA output, 3-channel HDMI output, VGA 1/HDMI 1 outputs the same video source. VGA2/HDMI2 outputs the same video source. Supports 4K output
Multi-screen DisplayCustomized display

Max. 36-channel local live view

Max.16-channel PCAPP live view

Third-party SupportOnvif, RTSP, Sony, Panasonic, Axis, Arecont, Pelco,Canon, Samsung
Operating SystemEmbedded Linux OS
Operation InterfaceWEB(PCAPP), local GUI

Compression

Video CompressionSmart H.265+/Smart H.264+/H.265/H.264
Audio CompressionG.711A/G.711U/PCM/G726

Network

ProtocolHTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P
Mobile PhoneDMSS
InteroperabilityONVIF (Profile S, T and G), CGI, SDK
BrowserChrome, PCAPP, IE9 or higher, Firefox
Network ModeNIC binding mode such as multiple-address mode, load balance, fault-tolerance, etc

Record Playback

Multiple-channel PlaybackMax. 16-channel playback
Record SearchSearch video detection/manual record/IO alarm/intelligent event/all record file
Storage MediumInternal HDD, SAS disk array enclosure
Backup MethodHDD, peripheral USB storage device
Playback FunctionPlay, pause, stop, fast forward, fast backward, reverse play, frame by frame play

Full-screen, backup (clip/file), snapshot, digital zoom, audio on/off

Storage

HDD Group8
RAIDRAID 0/1/5/6/10
Storage PoolN/A

Alarm

General AlarmMotion detect, tampering, local alarm
Anomaly AlarmIPC offline alarm, storage error, HDD full, IP conflict, MAC conflict, login lock, AI module temperature alarm, AI module offline, fan malfunction
Intelligent AlarmHuman face detection, human face recognition, video metadata (person/vehicle/non-motor vehicle), IVS, plate recognition, people counting, smoking, call
Alarm LinkageRecord, snapshot (full image), local external alarm output, IPC external alarm output, access & control, audio prompt, buzzer, log, preset, email

Peripheral Interface

Audio Input1-channel, RCA port (reserved)
Audio Output2-channel, RCA port, speaker output, audio linkage output
Alarm Input16-channel
Alarm Output8-channel
Internal HDD8 slots, SATA3.0. Max.16T/HDD
eSATA1 port
SASN/A
RS-2321 port, for debug or transparent COM data
RS-4851 port, control peripheral PTZ and so on

Supports various protocols

USB4 ports

2 USB2.0 port at the front panel and 2 USB3.0 port at the rear panel

HDMI3 ports; support 4K output
VGA2 ports
Network4 RJ-45 10/100/1000Mbps self-adaptive Ethernet ports
Power1 port
PoEN/A

Parametri generali

Power Supply100V AC–240V AC 50±2%Hz
Power Consumption40W (without HDD, idling)

136W (all HDDs connected)s

Net Weight8.55 kg (18.85 lb)
Gross Weight10.9 kg (24.03 lb)
Dimensions

(W × L × H)

Chassis: 439.7 mm × 446.2 mm × 89 mm

(17.31 ” × 17.57 ” × 3.50 “)
Max. size: 481.7 mm (with hanger) × 446.2 mm × 90.8 mm (with feet mat) (18.96 ” × 17.57 ” × 3.57 “)

Packaging Dimensions

(W × L × H)

With Packaging: 562 mm × 599 mm × 235 mm

(22.13 ” × 23.58 ” × 9.25 “)
Protection box: 491 mm × 584 mm × 631 mm

(19.33 ” × 22.99 ” × 24.84 “)

Operating Conditions0 °C to +45 °C (+32 °F to +113 °F)/10%RH–90% RH
Strorage Conditions0 °C to +40 °C (+32 °F to +104 °F)/30%RH–85% RH
Operating Altitude5000 m (16404.20 ft)
Installation ModeDesktop/rack
CertificationsCE: CE-LVD: EN 60950-1/IEC 60950-1

CE-EMC: EN55024,EN55035, EN50130-4,EN60950-1

FCC: Part 15 Subpart A

UL: 60950-1 and CAN/CSA C22.2 No. 60950-1-07

Funzionalita telecamere

,

Tipo ottica. Motorizzata / Fissa
