IPC-HFW3549E-AS-LED

IPC-HFW3549E-AS-LED-Bullet IP AI 5MP 3.6 LED Full-color

SKU: IPC-HFW3549E-AS-LED Categories: , , Tag:

Bullet IP AI 5MP 3.6 LED Full-color 12V/PoE
Telecamera bullet IP AI WizSense Full-color da interno/esterno IP67, sensore CMOS progressivo 1/2.7″, risoluzione 5 MP a 20fps, H.265+, portata LED fino a 30 m, ottica fissa M12 3.6 mm ƒ1.0, luminosità 0.003 lux ƒ1.0, 1 porta LAN 100 Mbps, 1 ingresso e 1 uscita allarme, 1 ingresso e 1 uscita audio con microfono integrato, 3D NR, WDR 120 dB, protezione perimetrale, SMD Plus, micro SD card (256 GB), alimentazione 12 Vdc/PoE <8.4 W

Camera IPC-HFW3549E-AS-LED
Image Sensor1/2.7”5Megapixel progressive CMOS
Max. Resolution2592 (H) × 1944 (V)
ROM128 MB
RAM512 MB
Scanning SystemProgressive
Electronic Shutter SpeedAuto/Manual 1/3 s–1/100,000 s
Min. Illumination0.003 Lux@F1.0
S/N Ratio> 56 dB
Illumination Distance30 m (98.4 ft) (Warm light)
Illuminator On/Off ControlAuto/Manual
Illuminator Number1 (Warm light)
Pan/Tilt/Rotation RangePan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360°
Lens
Lens TypeFixed-focal
Mount TypeM12
Focal Length2.8 mm; 3.6 mm
Max. ApertureF1.0
Field of View2.8 mm: Horizontal 98° × Vertical 71° × Diagonal 129°

3.6 mm: Horizontal 77° × Vertical 56° × Diagonal 101°

Iris TypeFixed
Close Focus Distance2.8 mm: 1.2 m (3.9 ft)

3.6 mm: 2.4 m (7.9 ft)

DORI DistanceLensDetectObserveRecognizeIdentify
2.8 mm56.0 m

(183.7 ft)

22.4 m

(73.5 ft)

11.2 m

(36.7 ft)

5.6 m

(18.4 ft)

3.6 mm80.0 m

(262.5 ft)

32.0 m

(105.0 ft)

16.0 m

(52.5 ft)

8.0 m

(26.3 ft)

Professional, Intelligent
IVS (Perimeter Protection)Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
Intelligent SearchWork together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video CompressionH.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart CodecSmart H.265+/ Smart H.264+
Video Frame RateMain stream: 2592 × 1944 @1–20 fps
2688 × 1520 @1–25/30 fps
Sub stream: 704 × 576 @1–25 fps/704 × 480 @1–30 fps
Third stream: 1280 × 720@1–25/30 fps
Stream Capability3 streams
Resolution5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate ControlCBR/VBR
Video Bit RateH.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps
Day/NightColor/B/W
BLCYes
HLCYes
WDR120 dB
Scene Self-adaptation (SSA)Yes
White BalanceAuto/natural/street lamp/outdoor/manual/regional custom
Gain ControlAuto/Manual
Noise Reduction3D DNR
Motion DetectionOFF/ON (4 areas, rectangular)
Region of Interest (RoI)Yes (4 areas)
Smart IlluminationYes
Image Rotation0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.)
MirrorYes
Privacy Masking4 areas
Audio
Built-in MICYes
Audio CompressionG.711a; G.711Mu; G726
Alarm
Alarm EventNo SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD
Network
NetworkRJ-45 (10/100 Base-T)
SDK and APIYes
ProtocolIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
Cyber SecurityVideo encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
InteroperabilityONVIF(Profile S/Profile G/Profile T);CGI;P2P;Milestone;

Genetec

User/Host20 (Total bandwidth: 64 M)
StorageFTP; SFTP; Micro SD card (support max. 256 G); NAS
BrowserIE: IE8, IE9, IE11
Chrome
Firefox
Management SoftwareSmart PSS; DSS; DMSS
Mobile PhoneIOS; Android
Certification
CertificationCE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Port
Audio Input1 channel (RCA port)
Audio Output1 channel (RCA port)
Alarm Input1 channel in: 5mA 3V–5V DC
Alarm Output1 channel out: 300mA 12V DC
Power
Power Supply12V DC/PoE
Power Consumption< 8.4W
Environment
Operating Conditions-40°C to +60°C (-40°F to +140°F)/less than 95%
Strorage Conditions-40°C to +60°C (-40°F to +140°F)
Ingress ProtectionIP67
Structure
CasingMetal
Dimensions192.7 mm × 70.5 mm × 66.4 mm

(7.6″ × 2.8″× 2.6″) (L × W × H)

Net Weight590 g (1.3 lb)
Gross Weight780 g (1.7 lb)
